Product Details:
Payment & Shipping Terms:
|
| Electromotor: | DC Brushless Motor | Rotating Direction: | Clockwise/Anticlockwise |
|---|---|---|---|
| Rotating Speed: | Stepless 100-1000rpm | Disc Diameter: | 250mm |
| High Light: | metallurgical laboratory equipment,metallurgical sample preparation equipment |
||
iGrind-420 was controlled by single chip microcomputer, equips with ABS sewage collection plate and cover, it is the latest product with a new and beautiful appearance.
Features:
1, Adopts stepless speed 100-1000rpm, support clockwise and anticlockwise rotation direction.
2, High definition LCD touch screen, clear to display working parameters and easy to use.
3, DC brushless motor and don’t need to replace the brush, used for a long time.
4, Firm and steady stainless steel grinding discs ensure the precision rotary balance.
5, Spindle leak-proof design ensures the bearing almost without damage and the super mute design brings a good experience.
6, With magnetic grinding disc design, it supports for fast disc replacing system, the plate is Teflon painted which makes no residue of changing polishing cloth.
Technical Specifications:
| Model | iGrind-420 | iGrind-421 | iGrind-420M | iGrind-421M |
| Disc Diameter | 250mm | 300mm | Magnetic 250mm | Magnetic 300mm |
| Rotating Speed | Stepless 100-1000rpm, with quick speed setting 250pm, 500rpm, 750rpm, 1000rpm | |||
| Rotating Direction | Clockwise/Anticlockwise | |||
| Electromotor | DC brushless motor, 220V, 1.1kw | |||
| Dimension | 725x900x360mm | |||
| Weight | 95Kg | |||
