20X Microscope Hardness Testing Machine Closed Loop Sensor 10 Steps Force

China 20X Microscope Hardness Testing Machine Closed Loop Sensor 10 Steps Force supplier
20X Microscope Hardness Testing Machine Closed Loop Sensor 10 Steps Force supplier 20X Microscope Hardness Testing Machine Closed Loop Sensor 10 Steps Force supplier

Large Image :  20X Microscope Hardness Testing Machine Closed Loop Sensor 10 Steps Force

Product Details:

Place of Origin: Dongguan/China
Brand Name: Q1-Test
Certification: CE
Model Number: HBE-3000A

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood Case
Delivery Time: 20 Working Days
Payment Terms: T/T
Supply Ability: 30 Sets per Month
Detailed Product Description
Vertical Space: 220mm Resolution: 0.005mm
Range: Hardness 8~650HBW Magnification: 20X
Horizontal: Space 135mm Hardness: Reading By Check Brinell Table
High Light:

portable metal hardness tester

,

hardness testing equipment



Closed Loop Sensor 10 Steps Force Electronic Brinell Hardness Tester with LCD



Model: HBE-3000A



HB-3000A Electronic Cast Iron Brinell Hardness Tester apply closed loop sensor loading, the electronic control system, has 10 steps testing force, it has high precision, high repeatability and stability, simple operation, etc



Features:

1, High accuracy compression sensor to feedback and the CPU control system to automatically compensate the test force lost during the testing.

2, 10 Steps Testing force for wider application;

3, Equips with stepping motor to realize automatic loading, dwell and unloading, with much lower noise during testing;

4, Die casting metal shell, stable structure, able to work under rugged environment;

5, Surface with car baking process, strong resistance of scratches, still brightness after years using;

6, Available to install optional Brinell measuring software, largely improve working efficiency.



Applications:

Suitable for cast iron, steel products, nonferrous metals and soft alloys etc. Also suitable for some nonmetal materials such as rigid plastics and bakelite etc.

Because of the wide test force range the Brinell test can be used on almost any metallic material. The part size is only limited by the testing instrument's capacity.



Strengths:

One scale covers the entire hardness range, although comparable results can only be obtained if the ball size and test force relationship is the same.

A wide range of test forces and b all sizes to suit every application

Nondestructive, sample can normally be reused



Weaknesses:

The main drawback of the Brinell test is the need to optically measure the indentation size. This requires that the test point be finished well enough to make an accurate measurement.

Each measurement takes 30 seconds not counting the sample preparation time.



Technical Specifications:

Model HBE-3000A
Brinell Scales HBW2.5/62.5, HBW2.5/187.5, HBW5/125, HBW5/750, HBW10/100, HBW10/1500, HBW10/3000, HBW10/250, HBW10/500, HBW10/1000
Test Force 62.5kgf(612.9N), 100kgf(980.7N), 125kgf(1226N), 187.5kgf(1839N), 250kgf(2452N), 500kgf(4903N), 750kgf(7355N), 1000kgf(8907N), 1500kgf(14710N), 3000kgf(29420N)
Vertical Space 220mm
Resolution 0.005mm
Dwell Time 0~60s
Hardness Range 8~650HBW
Magnification 20X
Standards GB/T231.2, JJG150
Horizontal Space 135mm
Hardness Reading By Check Brinell Table
Power Supply AC220V+5%,50~60Hz
Dimension (mm) 520*210*745mm
Weight 130kg

20X Measuring Microscope:
20X Microscope Hardness Testing Machine Closed Loop Sensor 10 Steps Force


Standard Delivery:

Microscope 20x 1pc Indenter 2.5, 5, 10mm Each 1pc
Test Block 3pcs Flat and “V” Shape Test Anvil Each 1pc
Power Cable 1pc Operation Manual Each 1copy
Fuse 2pcs Brinell Table 1copy


non-fumigation transport package:

20X Microscope Hardness Testing Machine Closed Loop Sensor 10 Steps Force
