DigitalTensionMeter_LTTS

China DigitalTensionMeter_LTTS supplier

Large Image :  DigitalTensionMeter_LTTS

Product Details:

Place of Origin: DONGGUAN
Brand Name: iqualitrol
Certification: CE
Model Number: LTTS

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Carton box
Delivery Time: 10 work days
Payment Terms: T/T
Supply Ability: 100 sets per month
Contact Now
Detailed Product Description
Measuring Frequency: 16 Msec (62.5 Samples / Sec) Sensing Roller: Deflection Of Sensing Roller ( Max. ) 0.2 Mm
Overload Capacity: 150 % Of Full Scale Temperature Coefficient: Zero : Less Than ±0.3% FS/ °C Span : Less Than ±0.01% FS/ °C
Display: Blue Back Light LCD Display Update Rate: 0.5 , 1.0 , 2.0 Or 4.0 Seconds , Selectable
High Light:

non destructive testing machine

,

fruit hardness tester



Spec:The LTTS Digital Tension Meter is a hand-held device which accurately measures the running as well as statictensions of a wide variety of process materials including yarns, fibers, wires, optical fibe



Features

* It employs the ‘three-roller principle’ of tension test.

* High accuracy and high resolution.

* Power is supplied by 4xAAA alkaline battery.

* With 4 measurement unit for selection, N, kg, lb, g.

* Current Value, Max. Value, Peak Value, Min Valuevcan be displayed at the same time.

* With 10 minutes auto power off and manual power off.

* The Meter takes 62 tension measurements per second and displays the average of these measurements.

* With data output, by USB cable or Bluetooth adapter.



General Specifications

Unit Kgf , gf , N , Lbf
Measuring Principle Strain gauge
Measuring Frequency 16 msec (62.5 samples / sec)
Sensing Roller Deflection of Sensing Roller ( max. ) 0.2 mm
Overload Capacity 150 % of Full Scale
Temperature Coefficient Zero : less than ±0.3% FS/ °C
Span : less than ±0.01% FS/ °C
Display Blue Back light LCD
Display Update Rate 0.5 , 1.0 , 2.0 or 4.0 seconds , selectable
Memory System Current Value , Max. Value , Peak Value , Min Value
Overrange Indicator Buzzer Alarm
Power Off 10 Minutes Auto , Manual
Data Output USB , Bluetooth
Roller Material Stainless Steel ( Standard )
Plastic ( Optional )
Maximum Speed 2000 m/min
Power Supply 4 x 1.5 AAA( UM-4 ) Battery
Operation Temperature 0 ~ 40 °C
Operation Humidity < 80 %
Weight 400 g
Size Main Unit : 149 x 70 x 30 mm
Sensor : 102 x 81 x 34 mm



Model Specifications



Model LTTS-200 LTTS-500 LTTS-1K LTTS-2K LTTS-5K LTTS-10K LTTS-20K LTTS-50K
Tension Range 0~0.2kgf 0~0.5kgf 0~1.0kgf 0~2.0kgf 0~5.0kgf 0~10.0kgf 0~20.0kgf 0~50.0kgf
0~200gf 0~500gf 0~1000gf 0~2000gf 0~5000gf
0~1.96N 0~4.9N 0~9.8N 0~19.6N 0~49N 0~98N 0~196N 0~490N
0~0.44Lbf 0~1.1Lbf 0~2.2Lbf 0~4.4Lbf 0~11Lbf 0~22Lbf 0~44Lbf 0~110Lbf
Resolution 0.001kgf 0.001kgf 0.001kgf 0.001kgf 0.01kgf 0.01kgf 0.01kgf 0.01kgf
1gf 1gf 1gf 1gf 1gf
0.001N 0.001N 0.001N 0.01N 0.01N 0.01N 0.01N 0.01N
0.001Lbf 0.001Lbf 0.001Lbf 0.001Lbf 0.01Lbf 0.1Lbf 0.1Lbf 0.1Lbf
Accuracy 1.0% or better 1.5% or better
