Micro Sensor Salt Spray Test Chamber Metal Corrosion Accelerated Stainless Steel

China Micro Sensor Salt Spray Test Chamber Metal Corrosion Accelerated Stainless Steel supplier
Micro Sensor Salt Spray Test Chamber Metal Corrosion Accelerated Stainless Steel supplier Micro Sensor Salt Spray Test Chamber Metal Corrosion Accelerated Stainless Steel supplier Micro Sensor Salt Spray Test Chamber Metal Corrosion Accelerated Stainless Steel supplier

Large Image :  Micro Sensor Salt Spray Test Chamber Metal Corrosion Accelerated Stainless Steel

Product Details:

Place of Origin: Dongguan/China
Brand Name: Q1-Test
Certification: CE
Model Number: HL-160-SS

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood Box
Delivery Time: 10 Working Days
Payment Terms: T/T
Supply Ability: 50 Sets per Month
Detailed Product Description
Dimension: Interior 160 X 100 X 550cm Temperature: NSS ACSS 35℃ ± 1℃
Safety Device: Over-temperature Protection PH Range: CASS: 3.0~3.2
Uniformity: ≦2. 0℃ Spray Quantum: 1.0~2.0(ml/80cm2/h)
High Light:

salt spray corrosion test chamber

,

salt mist chamber



Metal Corrosion Accelerated Stainless Steel Salt Spray Test Chamber with Micro Sensor



Brief Introduction:



Salt spray testing is popular because it is relatively inexpensive, quick, well standardized, and reasonably repeatable. Although there may be a weak correlation between the duration in salt spray test and the expected life of a coating in certain coatings such as hot dip galvanized steel, this test has gained worldwide popularity due to low cost and quick results.



Seawater Acidified Test (cyclic) can be used to test the relative resistance to corrosion of coated or uncoated aluminium alloys and other metals, when exposed to a changing climate of acidified synthetic seawater spray, followed by a high humidity, both at an elevated temperature.



This test is also referred to as a SWAAT test. Test specimens are placed in an enclosed chamber, and exposed to a changing climate that comprises the following 2 part repeating cycle. 30 minutes exposure to a continuous indirect spray of synthetic seawater solution, prepared in accordance with the requirements of the test standard and acidified (to pH 2.8 to 3.0) by the addition of acetic acid.



This spray is set to fall-out on to the specimens at a rate of 1.0 to 2.0ml/80 cm²/hour. This is followed by 90 minutes exposure to a high humidity climate of above 98%RH. The entire test cycle is at a constant chamber temperature of +49C (may be reduced to +24 to +35C for organically coated specimens). The number of cycle repeats and therefore the test duration is variable





Features:



1, Chamber material is made of P.V.C Sheet, sturdily and will not be out of shape.



2, Test chamber is heated from five directions to ensure the temperature is uniformity distributed.



3, Spray nozzle is specially made, enable to spray the salt water with considerable speed, then falls on the surface of samples.



4, Hot and moist air keeps the humidity in the test chamber conforms testing request.



5, High precision P.I.D. temperature controller limits the temperature difference within the range of ±0.1℃.





Specifications:

Please Note Small Type of 60 and 90 do not meet standard of ASTM B117.

Model HL-60-SS HL-90-BS HL-120-NS HL-160-NS HL-200-NS
Model (Touch Screen) HL-60-CS HL-90-CS HL-120-CS HL-160-CS HL-200-CS

Interior

dimensions

(mm)

W 600 900 1200 1600 2000
D 450 600 850 1000 1200
H 400 500 500 550 600

Exterior dimensions

(mm)

W 1130 1460 2200 2600 3000
D 630 910 1200 1450 1650
H 1070 1280 1450 1550 1600
Chamber Volume 108 L 270 L 480 L 800 L 1440 L
Solution Tank 15L 25 L 40 L
Power Supply AC 220V 50HZ AC 380V 50HZ
Ambient temp. & humid. range +5℃ ~ +35℃ / <85%RH
Testing Temperature NSS ACSS 35℃±1℃ / CASS 50℃±1℃
Air Temperature NSS ACSS 47℃±1℃ /CASS 63℃±1℃
Solution Consistence NaCl 5%
PH Value NASS ACSS:6.5~7.2 / CASS:3.0~3.2
Temperature fluctuation ≦±0.5℃
Temperature uniformity ≦2. 0℃
Temperature deviation ≦±2.0℃
Spray quantum 1.0~2.0(ml/80cm2/h)
Chamber Material polyvinyl chloride (PVC)
Heater Corrosion-resistant titanium tube
Temperature sensor Platinum Resistance (PT-100)
Safety device Over-temperature protection , leakage protection



Note:



1. The above specifications are for reference only, the actual specifications for the main quotation.

2. Custom made is available according to customers’ special requirements
