20°/45°/75°Gloss Meter (Inetgral Type) GM-247

: Large Image : 20°/45°/75°Gloss Meter (Inetgral Type) GM-247

Product Details:

Place of Origin:	DONGGUAN
Brand Name:	iqualitrol
Certification:	CE
Model Number:	GM-247

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Negotiable
Packaging Details:	Carton box
Delivery Time:	10 work days
Payment Terms:	T/T
Supply Ability:	100 sets per month

Contact Now

Detailed Product Description

Measuring Angle:	20°/45°/75°	Range:	0.1 ~ 200 Gloss Units
Measuring Area:	7 X 14 Mm（Ellipse）	Data Memorized:	254 Groups
Operating Conditions:	Temp ：0 ~ 40°C /Humidity ：< 85% RH	Power Supply:	3.7 V Lithium Ion Rechargeable Battery
Highlight:	non destructive testing instruments , fruit hardness tester

Spec:Glossmeter have different kinds of measurement angles.Generally,20°applies to High Gloss Materials,60°applies to Medium Gloss Materials,85°applies to Low Gloss Materials.

Features

*In’accordance’with’International’standard ASTMD523,ASTMD1455,ASTMC346,ASTMC584,ASTMD2457,DIN ENISO2813,DIN67530,ENISO7668,JISZ8741,MFT30064,TAPPIT480,GB9754,GB/T13891,GB7706andGB8807.Its technical parameters conform with JJG696-2002.

* Accurate measurement,good repetitiveness.

* Automatic calibration.Small in size,easy to carry.

* Intelligent design,rapid measurements.

* Able to store 254 groups of measurements.

* Applies USB,Bluetooth data output.

* Bulit-in lithium ion rechargeable battery.

* Backlight display,suitable for low light environment.

Specifications

Display	4 Digits Backlit LCD
Measuring Angle	20°/45°/75°
Range	0.1 ~ 200 Gloss Units
Gloss Units	GU
Accuracy	±1.0 GU
Resolution	0.1
Repeatability	±0.5 GU
Measuring Area	7 x 14 mm(Ellipse)
Data Memorized	254 Groups
Operating Conditions	Temp :0 ~ 40°C
Operating Conditions	Humidity :< 85% RH
Power Supply	3.7 V Lithium Ion Rechargeable Battery
Dimensions	140 x 45 x 75 mm
Weight	305 g(Including Batteries)
Standard Accessories	Main Unit
	Holder with Calibration Standard
	AC Adapter
	Optical Cleaning Cloth
	Carrying Case(B04)
	Operation Manual
Optional Accessories	USB Data Cable with Software
Optional Accessories	Bluetooth Data Adapter with Software
