Paper Moisture Meter MC-7828PP

China Paper Moisture Meter MC-7828PP supplier

Large Image :  Paper Moisture Meter MC-7828PP

Product Details:

Place of Origin: DONGGUAN
Brand Name: iqualitrol
Certification: CE
Model Number: MC-7828PP

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Carton box
Delivery Time: 10 work days
Payment Terms: T/T
Supply Ability: Negotiable
Contact Now
Detailed Product Description
Range: 0~80% Accuracy: ±(0.5%n+1)
The Statistics Available: Last Value / Mean Value / Max. Value / Min. Value / Number Of Readings Memory: 240 Groups
Operatin Conditions: Temperature 0~50ºC/ Humidity <90%RH
High Light:

non destructive testing machine


non destructive testing instruments


Spec:This instrument uses contact measurement. The moisture of the measured objects is measured by measuring the electrical conductivity between two electrodes.



* With storage and statistical functions. Can store 240 groups of measurements.

* Two presentations, digital display and color coded LED indication.

* Use the exclusive Micro-computer LSI circuit and crystal time base to offer high accuracy measurement. It can obtain automatically the temperature corrected moisture value.

* Use USB data output to connect with PC.

* Provide Bluetooth data output choice.



Sensor Type Contact Type
Range 0~80%
Accuracy ±(0.5%n+1)
Resolution 0.1
Display LCD
LED Indicator Green LED Represents a Safe,Air-dry State
Yellow LED Represents a Borderline State
Red LED Represents a Damp State
The Statistics Available Last value / Mean value / Max. value / Min. value / Number of Readings
Memory 240 groups



Temperature 0~50ºC
Humidity <90%RH
Power Supply 4x1.5V AAA Size(UM-4)Battery
Dimensions Main Unit 150x65x30mm
Sensor 265x44x44mm
Length of electrode 77mm
Cross section size of electrode 14x1mm
Gap between 2 electrodes 4mm
Weight(Not Including Batteries) 280g
Standard Accessories Main Unit
Carrying Case (B04)
Optional Accessories USB Data Cable with Software
Bluetooth Data Adapter with Software
