Product Details:
Payment & Shipping Terms:
|
| Range: | 0~80% | Accuracy: | ±(0.5%n+1) |
|---|---|---|---|
| Memory: | 240 Groups | Operatin Conditions: | Temperature 0~50ºC/ Humidity <90%RH |
| Highlight: | non destructive testing machine,non destructive testing instruments |
||
Paper Moisture Meter MC-7828PP
Brief Introduction:
This instrument uses contact measurement. The moisture of the measured objects is measured by measuring the electrical conductivity between two electrodes.
Features:
1, With storage and statistical functions. Can store 240 groups of measurements.
2, Two presentations, digital display and color coded LED indication.
3, Use the exclusive Micro-computer LSI circuit and crystal time base to offer high accuracy measurement. It can obtain automatically the temperature corrected moisture value.
4, Use USB data output to connect with PC.
5, Provide Bluetooth data output choice.
Technical Specifications:
| Sensor Type | Contact Type | |
| Range | 0~80% | |
| Accuracy | ±(0.5%n+1) | |
| Resolution | 0.1 | |
| Display | LCD | |
| LED Indicator | Green LED Represents a Safe,Air-dry State | |
| Yellow LED Represents a Borderline State | ||
| Red LED Represents a Damp State | ||
| The Statistics Available | Last value / Mean value / Max. value / Min. value / Number of Readings | |
| Memory | 240 groups | |
|
Operatin Conditions |
Temperature | 0~50ºC |
| Humidity | <90%RH | |
| Power Supply | 4x1.5V AAA Size(UM-4)Battery | |
| Dimensions | Main Unit | 150x65x30mm |
| Sensor | 265x44x44mm | |
| Length of electrode | 77mm | |
| Cross section size of electrode | 14x1mm | |
| Gap between 2 electrodes | 4mm | |
| Weight(Not Including Batteries) | 280g | |
| Standard Accessories | Main Unit | |
| Sensor | ||
| Carrying Case (B04) | ||
| Manual | ||
| Optional Accessories | USB Data Cable with Software | |
| Bluetooth Data Adapter with Software | ||
