Product Details:
Payment & Shipping Terms:
|
| Dimension: | Internal 72L, 40 X 45 X 40cm | Temperature: | Range RT～250℃ |
|---|---|---|---|
| Door: | Single Door | Heating Time: | RT~100℃ Within 10 Min |
| Material: | Internal SUS304# Mirror Stainless Steel | Insulation: | Glass Wool |
| Highlight: | hot air circulation drying oven,vacuum drying oven |
||
PID Controll Uniform Temperature Industrial Drying Oven with SUS304# Mirror Stainless
Brief Introduction:
Bench-top forced air oven is designed to meet both manufacturing and laboratory requirements. Our standard ovens are in stock and ready to ship.
Features:
1, Oven exterior material is high quality Cold Rolled Steel with surface treatment, nice appearance and durable.
2, Interior material is SUS304# mirror stainless steel with excellent heat resistance and easy to clean.
3, Unique combination of bottom scattered wind and heater, centrifugal turbine cycle effectively extend using life of fan.
4, Temperature uniformly distributed in the interior chamber, loop fan is automatically closed after temperature reaches setup.
5, With over-heat protection switch and power off memory function
6, The Ovens are widely used in kinds of composite materials, like electric parts, rubber, plastics, aerospace and automotive industries, etc.
7, Custom made maximum temperature range from room temperature to 500℃.
8, Vacuum oven is available according to specific applications.
Technical Specifications:
| Model | QHL-452 | QHL-602 | QHL-902 | QHL-1002 | QHL-1202 | |
|
Interior dimensions mm |
W | 450 | 500 | 600 | 1000 | 900 |
| H | 400 | 600 | 900 | 1000 | 1200 | |
| D | 400 | 500 | 500 | 1000 | 500 | |
|
Exterior dimensions mm |
W | 660 | 750 | 830 | 1200 | 1090 |
| H | 820 | 1160 | 1580 | 1600 | 1800 | |
| D | 520 | 620 | 680 | 1200 | 670 | |
| Power | AC380V, 50/60HZ, Three-phase (Specified by User) | |||||
| Control System | Hot air circulation control mode | |||||
| Ambient temp. & humid. Range | +5℃ ~ +35℃ / <85%RH | |||||
| Temp. range | RT+20℃~300℃(The maximum operating temperature recommend ≤260℃) | |||||
| Heating up time | RT~100℃within 10 min | |||||
| Temp. uniformity | ±1.5℃ | |||||
| Temp. constancy | ±0.5℃ | |||||
| Temp. accuracy | ±0.1℃ | |||||
| Interior material | SUS304# mirror stainless steel | |||||
| Exterior material | high quality Cold Rolled Steel with surface treatment | |||||
| Insulation | Glass wool | |||||
| Safety devices | Overheat protector, Magnetic switch, Porcelain fuse, Alarm system | |||||
| Accessories | Adjustable Shelf 2pcs, Overheating protective device | |||||
Note:
1, At 20℃ ambient temperature or 25℃ water temperature and non-loaded.
2, The above specifications are for reference only, the actual specifications for the main quotation.
3, Interior dimension is available for custom made.
