Product Details:
Payment & Shipping Terms:
|
| Display: | LCD | Beaufort Scale: | Force |
|---|---|---|---|
| Data Memorized: | 24 Groups | Sampling Rate: | Reading Per Second Approx |
| Automatic Power Off: | 0~9 Minutes Set By Users | Humidity: | <80%RH |
| Highlight: | non destructive testing instruments,fruit hardness tester |
||
Spec:Wide applications: use to check air conditioning & heating systems , measure air velocity, wind speed, temperature, etc.
Features
* Wide applications: use to check air conditioning & heating systems , measure air velocity, wind speed, temperature, etc.
* Multifunctional. the measurement unit can be selected according to different requirements.
* Maximum value data hold function.
* DATA HOLD function for storing 24 groups of datas.
* Low-friction ball-bearing design allows free vane movement.
* Separate type design, convenient to measure.
* Automatic Power off, 0-9 minutes set by users.
* Use USB/RS-232 data output to connect with PC.
* Provide Bluetooth data output choice.
Test Range Specifications
| Range | Resolution | Accuracy | ||
| Air Velocity | m/s(meters/sec) | 0.4~45.0 | 0.1. | ±(2%n+0.1m/s) |
| km/h(kilo-meters/hour) | 1.4~162.0 | 0.1 | ±(2%n+0.1km/h) | |
| Ft/min(feet/minute) | 80~8860 | 0.1 | ±(2%n+1ft/min) | |
| Knots(nautical MPH) | 0.8~88.0 | 0.1 | ±(2%n+0.1nots) | |
| Air Flow | CMM(cubic meters/min) | 0~9999 | 0.001~1 | ±(2%n+1m³/min) |
| CFM(cubic ft/min) | 0~9999 | 0.001~1 | ±(2%n+1ft³/min) | |
| Beaufort Scale | 0~12 | 0.1 | ±0.5 | |
| Direction ( Only AM - 4836C ) | 0~360° | 22.5° | ±22.5° | |
| Wave Height ( Meter ) | 0~14 | 0.1 | ±0.1 | |
| Air Temperature | 32~140°F | 0.1°F | 0.9°F | |
| 0~60°C | 0.1°C | 0.5°C | ||
Specifications
| Model | AM-4836V | AM-4836C | |
| Display | LCD | ||
|
Measurement Units |
Air Velocity | m/s,km/h,ft/min,knots | |
| Air Flow | CMM(m³/min),CFM(ft³/min) | ||
| Beaufort Scale | Force | ||
| Wave Height | m | ||
| Direction | ------ | º from The North Diection | |
| Temoerature | ºC,ºF | ||
| Data Hold | Maximum Value | ||
| Data Memorized | 24 Groups | ||
| Sampling Rate | Reading Per Second Approx | ||
| Sensors | Air Velocity/Flow Sensor | Vane Arms with Low-friction Ball Bearing | 3-cup Probe |
| Direction Probe | ------ | Low Friction Probe | |
| Temperature Sensor | Precision Thermistor | ||
| Automatic Power Off | 0~9 Minutes Set by Users | ||
|
Operating Conditions |
Temperature | 0~50ºC(32~122ºF) | |
| Humidity | <80%RH | ||
| Power Supply | 4x1.5V AAA(UM-4)Battery | ||
| Dimensions | Main Unit | 156x67x28 mm(6.1x2.6x1.1 inch) | |
| Sensor | Sensor Head:72mm Diameter | Velocity Sensor:65x65x115mm | |
| ------ | Direction Sensor:86x67x115mm | ||
| Weight (Including Batteries) | 260g | 375g | |
| Standard Accessories | Main Unit | ||
| Carrying Case(B04) | Carrying Case(B10) | ||
| Operation Manual | |||
| Sensor | Velocity Sensor | ||
| ------ | Direction Sensor | ||
| Optional Accessories | RS-232C Data Cable with Software | ||
| Bluetooth Data Adapter with Software | |||
