| Principle: | F Magnetic Induction /NF Type Eddy Current | Range: | 0~12mm/0~480mil |
|---|---|---|---|
| Resolution: | 0.01mm/0.1mm | Accuracy: | ±1~3%or±0.2mm |
| Automatic Power Off: | √ | Operating Conditions: | Tempersture 0~50ºC/ Humidity <80%RH |
| High Light: | non destructive testing machine,non destructive testing instruments |
||
Coating Thickness Gauge CM-8829H for Non-magnetic Materials on Magnetic Materials
Application:
The F probes measure the thickness of non-magnetic materials on magnetic materials.
Features:
* Measuring principle: magnetic induction (F).
* Two measurement mode: Single and Continuous(Notice:Continuous mode is convenient to measure the coating thickness of curved objects and tiny objects.)
* Metric/imperial system selectable.
* Manual or automatic shut down.
* Automatic memory of calibration value,and automatic recognize the substrate.
* Operation process have buzzing reminder,while no buzzing in continuous mode.
* Use USB/RS-232 data output to connect with PC.
* Provide Bluetooth data output choice.
Principle:
| Principles | Applications | Examples |
| F Type Magnetic Induction (Iron Base) |
Measure the thickness of non-magnetic materials on magnetic materials | Galvanizing layer, lacquer layer, porcelain enamel layer, phosphide layer, copper tile, aluminium tile, some alloy tile, paper etc |
Specifications:
| Principle | F Magnetic Induction | √ |
| NF Type Eddy Current | √ | |
| Range | 0~12mm/0~480mil | |
| Resolution | 0.01mm/0.1mm | |
| Accuracy | ±1~3%or±0.2mm | |
| Min.Radius Workpiece | convex 20mm/concave 50mm | |
| Min.Measuring Area | 16mm | |
| Min.Sample Thickness | 0.3mm | |
| Metric/Imperial | Convertible | |
| Battery Indicator | Low Battery Indicator | |
| Automatic Power Off | √ | |
| Operating Conditions | Tempersture | 0~50ºC |
| Humidity | <80%RH | |
| Power Supply | 4x1.5V AAA(UM-4)Battery | |
| Dimensions | 126x65x27mm | |
| Weight(Not Including Batteries) | 210g | |
