| ICT-500: | Tension Range (50-500N) | Value Display: | LCD Digital Display, Convenient For Fast And Clear Read Data |
|---|---|---|---|
| Unit Selection: | With OZ, Kgf, N, Lbf Four Units Can Be Set | Application: | Electric Power Industry, Communication Industry, Ropeway Transportation Industry, Construction Industry |
High-Precision Portable Cable/Wire Rope Tension Meter
for Accurate Handheld Measurements
Main uses and scope of application:
The iqualitrol hand held wire rope tensiometer, electronic digital graphic measurement instrument.
Can be used to measure the tension of steel cable, widely used in the electric power industry, communication industry, ropeway transportation industry, construction industry, testing institutions and other industries. accurately measure the tension and process the data systematically.
Product Features:
1, LCD digital display, convenient for fast and clear read data;
2, Real-time, peak, the two working modes of arbitrary switch;
3, With OZ, Kgf, N, lbf four units can be set;
4, You can store five different wire sizes for easy testing in different scenarios.
Technical Specifications:
| model number | iCT-500 | iCT-1500 | iCT-2500 |
| Tension Range (N) | 50-500 | 150-1500 | 250-2500 |
| Steel cable size | 1/8”, 5/32”, 3/16”, 7/32”, 1/4” | ||
| Size | 138×215mm | ||
| Net weight | 930g | ||
| power supply | A 3.7V lithium battery | ||
