Weights Low Loading Digital Brinell Hardness Tester iqualitrol HBS-62.5 with Manual Turret

China Weights Low Loading Digital Brinell Hardness Tester iqualitrol HBS-62.5 with Manual Turret supplier

Large Image :  Weights Low Loading Digital Brinell Hardness Tester iqualitrol HBS-62.5 with Manual Turret

Product Details:

Brand Name: iqualitrol
Model Number: HBS-62.5

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: Plywood Box
Delivery Time: 3 Working Days
Payment Terms: T/T
Supply Ability: 10 Sets per Month
Detailed Product Description
Model: HBS-62.5, Manual Turret Data Process: USB, RS232 Interface, Convenient For Process Data
Display: Digital Micrometer Eyepiece, Touch Screen Displays Of Hardness Value, Easy To Operate Storage Function: With Database Storage Function, Test Data Is Stored Synchronously And Can Be Exported



Weights Low Loading Digital Brinell Hardness Tester iqualitrol
HBS-62.5 with Manual Turret



Main Features:

1, Manual turret; weight loading test force system;

Cast iron casing, solid structure, good rigidity, reliable, durable, high test efficiency;



2, Adopt ARM high-speed processor, 5.6-inch LCD touch screen;

Digital micrometer eyepiece, touch screen displays of hardness value, easy to operate;



3, Dynamic display of the indenter during the test, real-time observation of the test status;

The screen can display the test force, indentation length, dwell time, number of measurements, etc.;



4, various hardness scales value conversion;

The test process is automated, the operation is simple, and there is no human error;



5, With database storage function, test data is stored synchronously and can be exported;

Equipped with USB and RS232 interfaces, convenient for users to process data;



6, Equipped with a built-in printer, which can directly print the test results;

Optional HYHB300 Brinell image measurement system;



7, The accuracy meets GB/T231.2, ISO6506-2 and American ASTM E10.



Technical Specifications:

Model HBS-62.5
Brinell Range 3.2-650HBW
Test force

9.80, 49, 98.07, 153.2, 294.2, 612.9(N)

1, 5, 10, 15.625, 30, 62.5(kgf)

Display 5-digit hardness value, 4-digit diagonal length (D1, D2),
Hold time, number of tests, average, standard deviation, return
Test force retention time(s) 1~99
Loading control Automatic (load/dwell/unload)
Conversion Rockwell, Superficial Rockwell, Vickers
Minimum measurement unit 0. 25μm(Subject to the choice of objective lens)
Total magnification Objective: Observe or measure 5X, measurement 10X (support special objective), Total magnification: 50X, 100X
Illumination Halogen light source
Data output Built-in printer
Vertical Space Maximum height 180mm
Indenter center to inner wall 125mm
Executive standard Accuracy meets GB231.2, ISO6506-2 and ASTM E10
Power supply AC220V±5%, 50~60Hz
Instrument weight About 85kg
Optional accessories XY table, CCD measurement system


Application range:

1, Determine the Brinell hardness of ferrous metals, non-ferrous metals and other materials;

Determine the Brinell hardness of bearing alloy materials such as lead-based alloys, babbitt alloys, tin-bismuth alloys, etc.;



2, Determine the Brinell hardness of certain non-metallic materials such as hard plastics and bakelite;

Determine the Brinell hardness of smaller parts produced by casting, forging, rolling and other processes.
