Detailed Product Description
Tube Diamter: 6mm, Length 2m Camera: 0.45 Mega Pixel
Bending: 360° All‐way Articulation Optional: Temperature Measure, WIFI
Application: Condensers, Piping And Turbines Depth Of Field: 20mm~150mm/ 10-100mm
High Light:

non destructive testing machine

,

fruit hardness tester


Power Generation Industrial Borescope Videoscope with 2M Insertion Tube and 5.7" LCD Monitor

Model: i35-6020F

Brief Introduction:
iqualitrol remote visual inspection videoscopes systems are designed to meet the demands of the modern industrial inspection environment. They offer portable and intelligent remote imaging solutions with a host of advanced, yet intuitive features, making them ideal remote visual inspection instruments.

A wider range of videoscope, fiberscopes and borescopes with various diameters and viewing options are available, making our videoscopes systems the most versatile inspection system suitable for a multitude of inspection requirements.

The compact and lightweight videoscopes achieve high quality inspections at any site, featuring versatile functionality and proven reliability under demanding circumstances.
   Power Generation Remote Visual Inspection Videoscopes Systems With 2M Insertion Tube And 5.7" LCD Monitor

Application:
Power Generation, Maintenance of heat exchanger pipes, condensers, piping and turbines in nuclear and thermal power Generation plants, and gearboxes of wind power generation facilities.

iqualitrol videoscopes are widely used in the fields of automotive manufacturing, car aftermarket, police security checking, aviation and aerospace area, special inspection institute, pharmaceutical machinery, non-destructive testing explosion-proof detection, ect.


Quality Assurance:
All products are complied with RoHS, CE and ISO standard and passed testing for temperature, waterproof, drop, vibration and pressure. Our vision is providing high-quality professional inspection instrument to every customer.
   Power Generation Remote Visual Inspection Videoscopes Systems With 2M Insertion Tube And 5.7" LCD Monitor
Operation Environment:

Host System Working Temperature-20°C~50°C, when 0°C below, the display needs preheating.
Camera Working Temperature-20°C~80°C, when 0°C below, please reduce oriented operation.
Store Temperature-23°C~63°C
Relative HumidityMaximum: 92%, non-condensing


Technical Specifications:

Camera Diameter(mm)Φ6mm
Camera MaterialTitanium alloy
Camera Pixel0.45 Mega Pixel
Depth of Field20mm~150mm/ 10-100mm
Angle of Field120°
Illumination30,000lx at a maximum
Bright/Chroma/Contrast Ratio AdjustmentManual, bright: six levels, chroma and contrast ratio: manual adjusting
Articulation360° all-way articulation
Bending Angle≥180°
Effective Working Length2m
Insert Tubetungsten-braided
Protecting Device of
Durability
Buffer protection device between the host and wear-resistant tube
DisplayHighlight 3.5 inches TFT LCD, can be replaceable for 5.7 inches display
Display Resolution640*480
Image Resolution640*480/1280*720/1920*1080
Video Resolution640*480/1280*720/1920*1080
Image/Video FormatJPEG/MOV
WIFI FunctionWIFI(optional)
IR FunctionIR/IR thermal imaging(optional)
MemoryStandard TF card:8G, Maximum: 32G
LanguageChinese, English, Russian… 8 languages
Data I/O portMicro-USB port,HDMI port
WaterproofCamera/Object glass/Tubes:IP67
Working Time≥8 hours
Weight≤0.55kg(with batteries)
Power SupplyRechargeable lithium battery(or built-in battery)
Battery Capacity3.7V 3200mAh
Power Consumption2W
Charging ParametersDC5V, Maximum current:1A


Power Generation Remote Visual Inspection Videoscopes Systems With 2M Insertion Tube And 5.7" LCD Monitor
